Winches

Luffing: 2 units luffing winches providing maximum luffing speed of 1.00m/min at full load

Main hoist: 4 units main hoisting winches for A-frame and 2 units for Jib, each capable of hoisting speeds 2m/min at full load of 1250MT and 5m/min at light/no load

Jib adjustment: 2 units jib adjustment winches, mounted on the A-frame, for adjustment of the Jib without load from 00 to 400 in respect to the A-frame.

20 MT aux. hoist: 2 units aux. hoisting winches for A-frame and 1 unit for Jib each capable of hoisting speeds of 10m/min at full load of 20 MT

Cargo handling: 2 units cargo winches capable of pulling 20 MT at 10m/min

Class anchor: 2 unit class anchor winch for handling the 6975 kg HHP bow anchor via 76 mm grade 3 anchor chain

• Accommodation: 45 persons

Sea transit The vessel can transit across seas without load as per ABS unrestricted service with boom and outrigger resting backwards

Winches

Luffing: 2 units luffing winches providing maximum luffing speed of 0.833m/min at full load

Main hoist: 4 units main hoisting winches each capable of hoisting speeds 2m/min at full load of 800MT and 4m/min at light/no load

60 MT aux. hoist: 2 units aux. hoisting winches each capable of hoisting speeds of 5m/min at full load of 38 MT and 10m/min at light/no load

Cargo handling: 4 units cargo winches capable of pulling 20 MT at 10m/min

Anchor mooring class: 1 unit class anchor winch for handling the 5515 kg AC14 bow anchor via 66 mm grade 3 anchor chain

• Accommodation: 34 persons

Sea transit The vessel can transit across seas without load as per ABS unrestricted service with boom and outrigger resting backwards

Lifting capacities

• Main hoists: 2 x 500 T + 2 x 300T
• JIB II hoists: 2 x 200 T
• JIB III hoists: 2 x 500 T
• Accommodation: 29 persons

Sea transit The vessel can transit across seas without load as per ABS unrestricted service with boom and outrigger resting backwards
